ACROW Tunnel Form System

System Description :

Acrow Tunnel Form System is designed for the construction of cut and cover tunnels, where the shoring tower, soffit form, and inner/outer tunnel forms are combined. Different shoring systems can be used as per project requirements.

This gives the system high versatility and load-bearing capacity while ensuring fast progressive pouring cycles and easy and safe shuttering, striking, and movement during all construction phases.

System Application :

  • ut and cover tunnels
  • Underpasses

Features :

banner

Cost Effective

banner

Heavy Duty

banner

Highly compatible

banner

Time saver

  • Allows floors, walls, and slabs concretion in one pour or stage.
  • Tunnel dimensions: thickness up to 1500 mm, height up to 15.00 m.
  • Special designs can solve curves, inclinations, and geometry variations.
  • Manual movable process.

System Main Components :

  • Half-tunnel steel forms
  • kicker forms
  • supporting props/struts / bracing
  • jacks & wheel units
  • connecting accessories
  • Tie-rods
  • Filler & keys
  • Supporting brackets/platforms
  • Stop- Ends
  • Steel Wall Boxouts
  • Access platforms & safety accessories

System Capacity :

Standard length of panels: 2.50, 1.25 & 0.625m.
Height of formwork: up to 3.0m. Extra height can be achieved with jacks & additional panels.
Length of formwork: up to 12.50 m on one l

Technical Data :
